DLD-B Commercial Die-Cast Aluminum Wide Beam Downlight 16-45W
Product Number: DLD04-B/DLD06-B/DLD08-B
Product Details
Description
The KWT DLD-B Commercial Wide-Beam Series is engineered for maximum operational efficiency and broad coverage across large commercial environments. Covering 16W to 45W across three models (DLD04-B, DLD06-B, DLD08-B) with large Ø125-215mm cutouts, this commercial downlight uses a durable die-cast aluminum frame for extended lifespan. Its fixed 84-degree beam angle provides uniform illumination in high-traffic retail environments, reducing the total number of fixtures required. With a high efficacy exceeding 120lm/W and universal AC100-240V input, it significantly lowers installation labor and long-term electricity costs.
Specification
| DLD-B Commercial Die-Cast Aluminum Wide Beam Downlight 16-45W | |||
| Product code | DLD04-B | DLD06-B | DLD08-B |
| Power | 16/20/25W | 18/25/32W | 25/32/45W |
| Size | D145*H92mm | D200*H110mm | D230*H118mm |
| Cut out | 125mm | 175mm | 215mm |
| Beam angle | 84° | 84° | 84° |
| Voltage | 220-240VAC | ||
| Lumen output | Lamp lumen 120Lm/W | ||
| CCT | 2700K, 3000K, 4000K, 5000K, 6500K, 2700K-6500K | ||
| Dimmable | ON/OFF, DALI, Triac, 0-10V, Bluetooth, Zigbee | ||
| Optics | Reflector | ||
| LED brand | CITIZEN / CREE | ||
| CRI | CRI90+ | ||
| Color Saturation | Rg=99 | ||
| SDCM | <3 | ||
| Materials | Die cast Aluminum | ||
| Installation | Recessed | ||
| Protection | IP20 | ||
| Finish | White / Black (Customizable) | ||
| Warranty | 3 years | ||
Size and drawing
Accessories
Datasheet
